4. 整机基本参数Basic parameters of the whole machine
|
5. 整机重量Total weight
|
6. 8890KG
|
|
7. 运输时总长shipping length
|
8. 7560(mm)
|
|
9. 运输时总高
10. Total height during transportation
|
11. 2850(mm)
|
|
12. 运输宽度
13. Transport width
|
14. 2260(mm)
|
|
15. 轮胎中心距离Tire center distance
|
16. 2400(mm)
|
|
17. 配重离地间隙
18. Counterweight ground clearance
|
19. 1065(mm)
|
|
20. 轮胎数量umber of tires
|
21. 8-825
|
|
22. 动臂长度Boom length
|
23. 3860(mm)
|
|
24. 斗杆长度Stick length
|
25. 2200(mm)
|
|
26. 工作范围
27. Working Range
|
28. 举升高度Maximum lifting height≤
|
29. 6880(mm)
|
|
30. 卸载高度Maximum unloading height≤
|
31. 5680(mm)
|
|
32. 下放深度Maximum lowering depth≤
|
33. 3780(mm)
|
|
34. 举升范围Maximum lifting range≤
|
35. 6880(mm)
|
|
36. 推土铲提升高度
37. Maximum lifting height of earth shovel≤
|
38. 300(mm)
|
|
39. 推土铲掘地深度≤
40. The maximum digging depth of dozer
|
41. 100(mm)
|
|
42. 夹木器抓举重量
43. Gripping weight of wood gripper
|
44. 600-900Kg
|
|
45. 夹木器开口宽度
46. Opening width of wood clamp
|
47. 1300(mm)
|
|
48. 动力系统Dynamical system
|
49. 发动机型号Model
|
50. 玉柴
|
|
51. 额定功率power
|
52. 62.5 KW
|
|
53. 冷却方式Cooling method
|
54. 水冷
|
|
55. 液压系统Hydraulic System
|
56. 额定工作压力Operating Pressure
|
57. 24mpa
|
|
58. 液压泵Main pump
|
59. 变量柱塞Variable plunger
|
|
60. 液压阀
|
61. 韩国进口Korea
|
|
62. 行走马达
|
63. 柱塞Plunger
|
|
64. 形式Shape
|
65. 负载敏感系统
66. Load Sensing System
|
|
67. 性能参数performance parameter
|
68. 铲斗容量（SAE）Bucket Capacity
|
69. 0.38m³
|
|
70. 爬坡能力Climbing ability
|
71. 30°
|
|
72. 挖掘力Maximum digging force≤
|
73. 8200N
|
|
74. 行走速度Travel speed
|
75. 35KM/h
|
|
76. 回转速度Unit swing speed
|
77. 9-11r/min
|
|
78. 液压油容量Hydraulic oil capacity
|
79. 90L
|
|
80. 燃油箱容量Hydraulic tank capacity
|
81. 120L
|
|
82. 驻车制动Parking brake
|
83. 断气刹Air break
|
|
84. 行车制动service brake
|
85. 气刹Kill
|
|
86. 稳定装置Stabilizers
|
87. 支腿Legs
|
